TAKE IT TO THE STREETS
The Talaria Sting is powered by an impressive 60V 38Ah lithium-ion battery which can be swapped and/or removed in seconds, allowing the possibility of a limitless range with a simple battery swap.
Using electric automobile grade LG 21700 cells combined with state-of-the-art programmed BMS, our torque and efficiency make this bike an outstanding performer on the road or off.
SPECIFICATIONS
- BATTERY 60V 38.4Ah Lithium LG Cells
- SUSPENSION FRONT Telescopic Forks
- SUSPENSION REAR Monoshock
- DISPLAY TFT
- MAX POWER 3700W @ 2100rpm
- BRAKES F: Hydraulic Disc, R: Hydraulic Disc
- PRIMARY DRIVE Chain
- TYRES F: 70/100-19, R: 80/100-19
- CHARGE TIME 4 Hours
Motor
Rated Voltage60v (DC)
Rated Power / Peak Power3700W @ 2100rpm
Shaft Output Torque29.5nm
TransmissionGearbox + Chain
Rated Torque / Peak Torque8.5nm / 31.8nm
Peak Efficiency96.6%
TypePMSM
Mounting PositionCentre Frame
Weight7kg
External Diameter180mm
Axial Length130mm
Cooling MethodAir Cooled
Controller
TypeFOC
Weight1.6kg
Dimensions (LxWxH)240mm x 110mm x 50mm
Peak Efficiency98.5%
Travelling Wave Current85A
Highest Temperature100 °C
Powertrain
Rated Rotation Speed4300 rpm
Range of Rotation Speed0-5300 rpm
Peak Efficiency98%
Range of Efficiency1.4mm - 22.5mm
Battery
Max Range *63 Miles
Battery60v 38.4A Lithium LG Cells
SpeedometerTFT Digital
Battery Life Time800 Cycles Before
Charger10A 60V
Charging Time **4 Hours
* Range is dependant on speed/weight/braking and other factors
** Charging time is from 0-100%
Chassis
Max Load100kg
Net Weight58kg
ForksManitou (Optional) / RST - DNM
Wheel TypeSpoke Wheels 19x1.6
Brakes4 Piston Caliper Hydraulic Brakes
Dimensions (LxWxH)1870mm x 780mm x 1040mm
Chassis - Swing Arm Material6061 T4 & T6 Aluminium Alloy
Chassis Construction MethodForged 8000 Tons of Pressure
Rear Shock AbsorberFastace with Linkage
Front Tyre Size70/100-19
Rear Tyre Size80/100-19
Chassis Weight9.5kg
Chassis SurfaceAnodizing Paint Treated
HeadlightLED
TyresCST
Brake Discs203mm
Minimum Ground Clearance270mm
NIGHTRIDER
The dash features a high-contrast OLED display, which will offer riders a clear data display with low power consumption. The display menu provides a range of information, which include top/average speed, range, battery data, riding mode, error codes, regen level and more.
The dash is also adjustable to allow different settings for different wheel sizes, sprocket sizes, motor regen levels, and changes between KM/H and MPH to enhance the compatibility of the bike.
